4 Channel Capacitance Manometer Controller No Rack Mount Tabs No Display, Pressure data via RS-232C Manual Included With RS232 Instructions Brand New, Surplus Equipment 6 Availabe

Surplus# 139
4 Channel Capacitance Manometer Controller
Export Prohibited Item
• Granville PN: 341581
• RS-232C Computer interface module

• No front panel displays or controls.

• Pressure Range: 0.1, 1, 10, 100 Torr max heads, 4 decades of pressure.

• Data Output Resolution: High 3 decades -2 digits, lowest decade -1 digit

• Output to Head: ±15 VDC, ±2%, at 250 mA

• Input from Head: 0-10 Vdc into 100 kohm

Gauge Types:
Any capacitance manometer transducer that requires ±15 Vdc power at <250 mA and outputs 0-10 Vdc proportional to pressure.

For Example:
• MKS Series: 220B, 221A, 222 A/B, 224, 227A/127A

• Leybold/Inficon Series: CM100, CM140, CM150


4-Channel, RS232 Capacitance Manometer Controller
Surplus# 139
SURPLUS-139Price: $1,830.00Surplus: $429.00

Click to enlargeReview Granville 341581 Manual Here

Export of This Vacuum Technology is PROHIBITED
Reason for Control:
• Nuclear Nonproliferation (NP)
• Anti-Terrorism (AT)
Capacitance Diaphragm Gauges, Capacitance Manometers, Baratrons, Including Support Products
(CDG, Pressure Transducers)
Are EXPORT CONTROLLED & NOT available for purchase to customers outside the United States
OR to US customers where this equipment has a final destination outside the United States.

Customers not meeting this criteria must purchase directly from the manufacturer.

The International Emergency Economic Powers Act and US Export Administration Regulations
PROHIBITS The Export Of This Vacuum Technology

Capacitance Diaphragm Gauges, Capacitance Manometers, Baratrons, Including Support Products
(CDG, Pressure Transducers)
• Classification 2B230 under Export Administration Regulations (EAR).

Reason for Control:
Nuclear Nonproliferation (NP) and Anti-Terrorism (AT).
