NW40 Platinum Coated <br> Ion Gauge Tube <br> GK-IR-NW40-PC-BR

GK-IR-NW40-PC-BR
Replacement Ion (Hot Filament) Gauge Tube
Glass Bayard-Alpert Type Ionization Vacuum Gauge
Broad Range Hot Cathode Ion Gauge Tube
NW40 (KF40) Port OD: Ø2.18"
• Platinum Coating
• Iridium Filament (Single)

Controller With Broad-Range Capability Required

Former LDS PN: 1050-1020-PC-BR-NW40
Varian Agilent Equivalent: K2500311 (564 Series)

Equivalents: 0564-K2500-311, 0564-K2500311, I-164-KF40



View All Ion Gauge Tubes		All NW40 Hardware



NW40 (KF40) UHV Conversion Hardware

Operating at a pressure below 10^-8?
Viton O-Ring Sealed compression ports limit the system pressure because of leakage and permeation.
Use Conflat Flanges & Copper Gaskets Instead!
Click Here To Change Port To Conflat Flange

BROAD-RANGE SPECIFICATIONS:
• X-ray Limit: 4x10^-10 torr
• Sensitivity: 6 torr^-1

Controller With Broad-Range Capability Required

Operating Pressure:
• AIR: 4x10^-10 torr to 5x10^-2 torr
• Argon: 4x10^-10 torr to 1x10^-1 torr

PLATINUM COATING
Shields the gauge elements from electrostatic charges at low pressures and drains off the static charges that can build up at high pressures.

Varian 564 Series Bayard-Alpert Tube Equivalent

NW40 Flange OD: 2.18"

***NW40 Flange Accessories Available Below***
NW40 Centering Rings
NW40 Clamps, All Types
NW40 Plastic Caps
