Click to enlarge8.00" Conflat Half Nipple
OAL: 5.50"

800-LF-VE
8.00" OD Conflat Half Nipple
DN160CF Non-Rotatable (Fixed)
Vacuum Essential

• 304 Stainless
• OD Polish

8.00" OD Conflat Flange (CF):
• Non-Rotatable (Fixed)
• UHV Ultra High Vacuum Flanges
• 6" Tube OD
• 20 Clearance (Thru) Holes
• 0.332" Bolt Hole Diameter

8" OD CFF Conflat Flange (CF800) Equivalents:
DN160CF, DN150CF, NW150CF, CF150, CF160, 800CF
800-600-LF 800-600-LF-VE


8.00" OD CF Half Nipple
Non-Rotatable
800-LF-VE

800-LF-VE$494.00

Click to enlarge
Click to enlarge
8.00" OD Conflat Series Hardware


Custom Adapters and Nipples



**This Vacuum Essential Includes**
• 8.00" OD Conflat HALF NIPPLE
• 1-Bolt Kit (800-BK Series)
• 10-Copper Gaskets (800-CG Series)
