Click to enlarge3.38" OD Conflat Nipple A: 3.44" (Short OAL)

338-200-NS
3.38" OD Conflat Full Nipple, Short Length
• 304 Stainless
• OD Polish

3.38" OD Conflat Flange (CF):
• Rotatable & Non-Rotatable Vacuum Flanges
• 2.00" Tube OD
• 8 Clearance (Thru) Holes
• 0.332" Bolt Hole Diameter

3-3/8" OD Conflat Flange (CF) Equivalents:
• 338CF, CF338, DN50CF, NW50CF, 3.375" CFF
338-200-N-S P108986 338-200-NS-VE 338-NS-VE


3.38" OD Conflat Flange
Full Nipple, 3.44" OAL
338-200-NS
338-200-NSPrice: $196.00Sale: $132.00

Click to enlarge
Click to enlarge
3.38" OD Conflat Series Hardware


Custom Adapters and Nipples
